TouchThink MES Terminal D Series
MES Terminal D Series features an 11.6″ display, Ideal for automatic production lines in smart factories. Support NFC and a variety of identification methods are customizable. Compatible with MES, realize production status real-time display and monitoring, support voice intercom and alarm light to deal with abnormal situations.
TouchThink RK3288 MES Terminal D Series
| Product Size | Resolution | Aspect Ratio | Contrast Ratio | Brightness | Quick Inquiry |
|---|---|---|---|---|---|
| 11.6″ | 1920*1080 | 16:9 | 1000:1 | 300 cd/m2 | Inquiry Now |
| Product Features |
|---|
Ultra-thin Frame Design
Industrial Technology Design
| Product Parameters | ||
|---|---|---|
| Hardware Parameters | CPU: RK3288, Cortex-A17 quad-core, 1.8GHz | Android 7.1/10.0, Linux4.4/Ubuntu18.04/Debian10.0/linux4.4+QT |
| Memory | 2GB DDR3 (Optional: 4GB/8GB) | |
| Storage | 16G eMMC (Optional: 32G/64G) | |
| Card reader | 13.56MHz, IC card reader (ISO14443-A, ISO14443-B) | |
| GPU | Mali-T764 | |
| Camera | 100W pixels | |
| LED indicator | Red/green/blue (combination) | |
| Screen Parameters | Panel Type | Industrial control screen |
| Viewing Angle | 85/85/85/85 (L/R/U/D) Full View | |
| Backlight Type | LED, use time >=50000H | |
| Response Time | 6.5ms | |
| Brightness | 300cd/m2 (can be customized =< 1500cd/m2) | |
| Display Color | 16.7M | |
| Contrast Ratio | 1000:1 |
| Touch Parameters | Projection capactivite touch Touch Point: 10-point Light Transmittance: >=88% Input Mode: handwriting or capactivite pen Standard Protocol:USB | Resistive touch 4-5wire/5 Wire Touch Point: single point Light Transmittance: >=78% Input Mode: Fingertip or stylus Standard Protocol:USB | Non-touch Light Transmittance: >=92% | ||
| Interface Parameters | DC Port | 1*DC2.1, Supporting 12V power input |
| HDMI | 1*HDMI, Supporting HDMI data output, up to 4K | |
| SIM | 1*SIM, Supporting various formats (Depending on 3G/4G module) | |
| Network interface | 1*LAN, 10M/100M/1000M adaptive Ethernet | |
| USB | 1*USB HOST，1*USB OTG | |
| Audio interface | 1*Audio I/O, Support audio input and output |
| Environment Parameters | Working Temperature | -10°C~60°C |
| Storage Temperature | -20°C~70°C | |
| Relative Humidity | Humidity: 95% Non-Condensing | |
| Vibration Protection | IEC 60068-2-64, Random, 5 ~ 500 Hz, 1 hr/axis | |
| Impact Protection | IEC 60068-2-27, Half sine wave, Lasting for 11ms |
| Other Parameters | Power input | DC 12V |
| Static power | 18W | |
| Body Color | Silver, Black Optional | |
| Installation Method | Supports snap-embedded,wall embedded,wall mounted,desktop,louvered,cantilever-mounted,boom-mounted,etc. | |
| Warranty Policy | Three years ( one year free warranty ) |
