Touch Think 4nd Gen A Series Windows J1900 All-In-One Panel PC
TPC156-W4
- Stylish and simple appearance, Independent mold opening
- High precision die-casting aluminum molding, Efficient heat dissipation
- Self-developed X86 architecture industrial main version
- Comply with EMC anti-electromagnetic interference standard
- Industrial-grade quality, Suitable for a variety of harsh environments
- Support desktop, Wall-mounted and multiple installation methods
Quick Inquiry
Touch Think Windows All-In-One PC:
TPC156-W4
TPC156-W4
Required fields are marked *, We’ll respond within 12 hours.
Product View
The whole aluminum alloy material, strong structure layout, no fan fully closed design, low power consumption, good scalability, practicability and EMC compatibility performance, designed for a variety of complex environment. It can support embedded, wall-mounted, cantilever and other installation modes, and is widely used in industrial control, military, communication, power and network automation fields.
| General Info | |
|---|---|
| Manufacturer | Touth Think |
| Product Manual |  TPC156-W4.pdf |
| Screen Size | 15.6 inch |
| Hardware Configuration | |
|---|---|
| CPU | Intel Celeron J1900 quad-core 1.99GHz (Maximum 2.4GHz) |
| Memory | 4G DDR3 1333/1600M（Optional：8G） |
| Storage | 64G SSD (Optional：128/256/512G) |
| Integrated Graphics | Intel HD Graphics |
| WiFi | 2.4GHz/5GHz, Dual frequencyWiFi |
| Bluetooth | BT4.0（Optional） |
| Operating System | Win7/10/Ubuntu/Centos/Redhat/Debian/Linux |
| Other | Support RTC real-time clock and timing switch |
| Product Model | |
|---|---|
| Non-Touch | TPC156-W401 |
| Capacitive Touch | TPC156-W411 |
| Resistive Touch | TPC156-W421 |
| Physical Characteristics | |
|---|---|
| Overall Dimensions | W389.6x H264x D63mm |
| Size of Opening | W371.8x H235.5mm |
| Interface Parameters | |
|---|---|
| Power key | 1*POWER |
| Power interface | 1*DC2.5, Supporting wide voltage 12V-36V power supply |
| USB | 2*USB 2.0, 2*USB 3.0 |
| Network interface | 2*LAN, 1*Realtek PCI-E NIC RTL8111H (Applicable to 1000Mbps) 1*Realtek PCI-E NIC RT8152B (Applicable to 1000Mbps) |
| HDMI | 1*HDMI, Support HDMI data input, and supports 1080P at most |
| SIM | 1*SIM, Supporting various formats (Depending on 3G/4G module) |
| VGA | 1*VGA, Analog signal transmission |
| COM | 2*RS232 |
| Audio interface | 1*Audio I/O, Support audio input and output |
| WiFi antenna | 2*WiFi antenna |
| Grounding column | Support (1*GND) |
| Screen Parameters | |
|---|---|
| LCD Size | 15.6″ TFT LCD |
| Resolution | 1920*1080 |
| Aspect Ratio | 16:9 |
| Viewing Angle | 85/85/85/85 (L/R/U/D) |
| Colour | 16.7M |
| Brightness | 300 cd/m2 |
| Contrast Ratio | 800:1 |
| Touch Parameters | |||
|---|---|---|---|
| Touch Type | Capacitive touch screen | Resistance touch screen | Non-touch |
| Touch Point | 10-point Touch Projection | Single Point | / |
| Transmittance | ≥88% | ≥78% | ≥92% |
| Input Mode | Handwriting or Capacitance pen | Fingertip or stylus | / |
| Controller communication | USB | USB | / |
| Reliability Parameters | |
|---|---|
| Working Temperature | -10°C~60°C |
| Storage Temperature | -20°C~70°C |
| Relative Humidity | Humidity: 95% Non-Condensing |
| Vibration Protection | IEC 60068-2-64, Random, 5 ~ 500 Hz, 1 hr/axis |
| Impact Protection | IEC 60068-2-27, Half sine wave, Lasting for 11ms |
| Product Certification | CCC/CE/FCC/EMC/CB/ROHS |
| Waterproof Grade | The front panel reaches IP65 protection level |
| Power Parameters | |
|---|---|
| Power input | DC 12V~36V |
| Static power | 18W |
| Installation Method |
|---|
| Packing List |
|---|
| Other Items | |
|---|---|
| Warranty | 3-Year |
| Color | Black / Silver |
| After-sales Service | Call Center and on-line Technical Support |
| Place of Origin | Guangdong, China |
| Express | UPS/DHL/Fedex/EMS,etc |
| Delivery Time | 1-3 Working Days |
| Packaging Details | Packed in Standard EXPORT Cartons |
| Delivery Port | Shenzhen/Hongkong |
| Customization | Logo,Packaging,Graphic |
