Outdoors High-Brightness A Series Monitor
These high-brightness industrial displays offer wide viewing angles, anti-glare coatings, and high contrast ratios ensuring excellent visibility and readability in outdoor environments, making them ideal for applications such as outdoor digital signage, AD players, and parcel lockers.
TouchThink A Series Outdoors High-Brightness Monitor
| Product Size | Resolution | Aspect Ratio | Contrast Ratio | Brightness | Quick Inquiry |
|---|---|---|---|---|---|
| 10.1″ | 1280*800 | 16:10 | 1000:1 | 700cd/㎡~1000cd/㎡ | Inquiry Now |
| 10.4″ | 1024*768 | 4:3 | 1000:1 | 700cd/㎡~1000cd/㎡ | Inquiry Now |
| 12.0″ | 1024*768 | 4:3 | 1000:1 | 700cd/㎡~1000cd/㎡ | Inquiry Now |
| 15.0″ | 1024*768 | 4:3 | 1000:1 | 700cd/㎡~1000cd/㎡ | Inquiry Now |
| 15.6″ | 1920*1080 | 16:9 | 800:1 | 700cd/㎡~1000cd/㎡ | Inquiry Now |
| Product Features |
|---|
Ultra-thin Frame Design
Industrial Technology Design
| Product Parameters | ||
|---|---|---|
| Hardware Parameters | CPU | RTD2513/RTD2556 |
| Material | Aluminum alloy | |
| Menu Language | Multilingual (default: English) | |
| Key Function | AUTO/MENU/POWER/LEFT/RIGHT | |
| Color | Black,Sliver Optional | |
| Video Input | PC-RGB:Format Up to 1920*1080@60HZ; PC-RGB:Color 16bit,24bit,32bit | |
| Screen Parameters | Panel Type | Industrial control screen |
| Viewing Angle | Wide view / full view | |
| Backlight Type | LED, use time >=50000H | |
| Brightness | 700cd/m2~1000cd/m2 | |
| Display Color | 16.7M | |
| Contrast Ratio | 1000:1 |
| Touch Parameters | Projection capactivite touch Touch Point: 10-point Light Transmittance: >=88% Input Mode: handwriting or capactivite pen Standard Protocol:USB | Resistive touch 4-5wire/5 Wire Touch Point: single point Light Transmittance: >=78% Input Mode: Fingertip or stylus Standard Protocol:USB | Non-touch Light Transmittance: >=92% | ||
| Environment Parameters | Working Temperature | -20°C~70°C |
| Storage Temperature | -30°C~80°C | |
| Relative Humidity | Humidity: 95% Non-Condensing | |
| Vibration Protection | IEC 60068-2-64, Random, 5 ~ 500 Hz, 1 hr/axis | |
| Impact Protection | IEC 60068-2-27, Half sine wave, Lasting for 11ms |
| Other Parameters | Power input | DC 12V~36V |
| Static power | 18W | |
| Installation Method | Supports snap-embedded,wall edbedded,wall mounted,desktop,louvered,cantilever-mounted,boom-mounted,etc. | |
| Warranty Policy | Three years ( one year free warranty ) |
