Industrial 4U Touch Server PC
Industrial 4U Computers with a 9-inch touchscreen combine the robust computing capabilities of a 4U form factor with the convenience and versatility of a touchscreen interface, tailored for industrial applications.
TouchThink Industrial Computer 4U Touch Series
| CPU | Product Size | Weights | Body Colour | Quick Inquiry |
|---|---|---|---|---|
| Intel Core I3/I5/I7 | 430*299*176mm | 7.5KG | Black | Inquiry Now |
| Product Features |
|---|
Ultra-thin Frame Design
Industrial Technology Design
| Product Parameters | ||
|---|---|---|
| Hardware Parameters | CPU: Intel Core/Pentium I3/I5/I7 | Windows 7/8/10, Server 2008/2012, Linux |
| Memory | 8GB DDR4 | |
| Storage | Standard: 1T mechanical hard drive with 4 * SATA3.0 + 1 * mSATA support [3] | |
| Display | 1 * VGA DB15 port + 1 * DVI port + 1 * HDMI port | |
| Audio Chip | Realtek ALC662 5.1 Channel HD Audio Codec, Support 1* MIC + 1 * Line-out + 1 * Line-in | |
| NIC chip | 1 * Intel I211AT + 1 * Intel I219-LM for 1000Mbps | |
| COM | Default RS232*1, reserved COM*4; Support: 4 * RS232 + 2 * RS232/RS485 [4] | |
| USB | 8*USB, default USB2.0*4, USB3.0*4 | |
| RJ45 | 2*RJ45 | |
| Interface Parameters | DC Port | 1*DC55*21 with thread, can support 12-36V wide voltage power supply |
| HDMI | 1*HDMI, Supporting HDMI data output, up to 4K | |
| SIM | 1*SIM, Supporting various formats (Depending on 3G/4G module) | |
| Network interface | 1*LAN, 10M/100M/1000M adaptive Ethernet | |
| USB | 2*USB 3.0 | |
| Heat Dissipation System | Intelligent fan cooling |
| Environment Parameters | Working Temperature | -10°C~65°C |
| Storage Temperature | -20°C~75°C | |
| Relative Humidity | Humidity: 95% Non-Condensing | |
| Vibration Protection | IEC 60068-2-64, Random, 5 ~ 500 Hz, 1 hr/axis | |
| Impact Protection | IEC 60068-2-27, Half sine wave, Lasting for 11ms |
| Expansion Slots | GPIO | 8 * GPIO |
| Fan Header | 3 * CPU Fan Header | |
| LPT Header | 1 * LPT Header | |
| Front Panel | 1 * Front Panel Header | |
| PS/2 | 1 * PS/2 Connector (keyboard or mouse) | |
| SMB Header | 1 * SMB Header |
| Other Parameters | Power input | DC 220V |
| Sizes | 430*299*176mm (L*W*H) | |
| Weights | 7.5KG | |
| Static power | 35W | |
| Body Color | Black | |
| Installation Method | Supports desktop and rack mounting | |
| Warranty Policy | Three years ( one year free warranty ) |
