TouchThink B Series Mini PC
Industrial Computer B Series with X86 architecture represents compact yet powerful computing solutions tailored for industrial environments. These devices leverage the versatile X86 architecture, typically powered by Intel processors such as Core i3/i5/i7 or Celeron CPUs, offering robust performance suitable for a wide range of industrial applications.
TouchThink Industrial Computer B Series
| CPU | Product Size | Weights | Body Colour | Quick Inquiry |
|---|---|---|---|---|
| J1900 | 199.5*213.1*58.3mm (L*W*H) | 1.9KG | Gun black | Inquiry Now |
| J4125 | 199.5*213.1*58.3mm (L*W*H) | 1.9KG | Gun black | Inquiry Now |
| Intel I3 | 199.5*213.1*58.3mm (L*W*H) | 1.9KG | Gun black | Inquiry Now |
| Intel I5 | 199.5*213.1*58.3mm (L*W*H) | 1.9KG | Gun black | Inquiry Now |
| Intel I7 | 199.5*213.1*58.3mm (L*W*H) | 1.9KG | Gun black | Inquiry Now |
| Product Features |
|---|
Ultra-thin Frame Design
Industrial Technology Design
| Product Parameters | ||
|---|---|---|
| Hardware Parameters | CPU: Intel Celeron J1900 quad-core 1.99G | Supports Windows/Ubuntu/Centos/Redhat/Debian systems |
| CPU: Intel Celeron J4125 quad-core 2GHz | Windows7/10/11; Ubuntu16.04.7/8.04.5/20.04.3; Centos7.6/7.8 | |
| CPU: I3-6100U 2.3GHz/I3-8145U 2.1GHz/I3-10110U 2.1GHz | Windows7/10/11; Ubuntu16.04.7/8.04.5/20.04.3; Centos7.6/7.8 | |
| CPU: I5-6200U 2.3GHz/I5-7200U 2.5GHz/I5-8265U 1.6GHz/I5-10210U 1.6GHz | Windows7/10/11; Ubuntu16.04.7/8.04.5/20.04.3; Centos7.6/7.8 | |
| CPU: I7-6500U 2.5GHz/I7-7500U 2.7GHz /I7-8565U 1.8GHz /I7-10210U 1.8GHz | Windows7/10/11; Ubuntu16.04.7/8.04.5/20.04.3; Centos7.6/7.8 | |
| Memory | 4GB/8GB/16GB/32GB/64GB Optional | |
| Storage | 64GB/128GB/256GB/512GB SSD, 1T/2T HDD Optional | |
| Integrated Graphics | Intel HD Graphic 520/InteL HD Graphic 620 | |
| Decoding Resolution | HDMI Support up to 4K 3840*2160 | |
| Network Support | 4G, Ethernet, wireless peripheral expansion,etc. | |
| Power On | Support | |
| Remote Wakeup | Support | |
| HD Support | Support | |
| Interface Parameters | DC Port | 1*DC55*21 with thread, can support 12-36V wide voltage power supply |
| HDMI | 1*HDMI, Supporting HDMI data output, up to 4K | |
| SIM | 1*SIM, Supporting various formats (Depending on 3G/4G module) | |
| Network interface | 1*LAN, 10M/100M/1000M adaptive Ethernet | |
| USB | 2*USB 3.0 | |
| Industrial terminals | 1*12P Phoenix terminal (power supply/232*1/485*1/CAN*1/GPIO*3) |
| Environment Parameters | Working Temperature | -10°C~60°C |
| Storage Temperature | -20°C~70°C | |
| Relative Humidity | Humidity: 95% Non-Condensing | |
| Vibration Protection | IEC 60068-2-64, Random, 5 ~ 500 Hz, 1 hr/axis | |
| Impact Protection | IEC 60068-2-27, Half sine wave, Lasting for 11ms |
| Other Parameters | Power input | DC 12V-36V |
| Sizes | 199.5*213.1*58.3mm (L*W*H) | |
| Weights | 1.9KG | |
| Static power | 15W | |
| Body Color | Gun black | |
| Installation Method | Supports desktop and rack mounting | |
| Warranty Policy | Three years ( one year free warranty ) |
