Medical M Series Android Panel PC
Medical M Series Android all-In-one panel PC designed with rugged construction to withstand the rigors of healthcare environments, featuring ruggedized enclosures that resist damage from cleaning agents, spills, and impacts. Feature touchscreen functionality, allowing touch with gloves.
TouchThink M Series Medical Grade Android All-In-One Panel PC
| Product Size | Resolution | Aspect Ratio | Contrast Ratio | Brightness | Quick Inquiry |
|---|---|---|---|---|---|
| 7.0″ | 1024*600 | 16:9 | 500:1 | 300 cd/m2 | Inquiry Now |
| 8.0″ | 1024*768 | 4:3 | 800:1 | 300 cd/m2 | Inquiry Now |
| 10.1″ | 1280*800 | 16:10 | 1000:1 | 300 cd/m2 | Inquiry Now |
| 10.4″ | 1024*768 | 4:3 | 1000:1 | 400 cd/m2 | Inquiry Now |
| 11.6″ | 1920*1080 | 16:9 | 1000:1 | 300 cd/m2 | Inquiry Now |
| 12.0″ | 1024*768 | 4:3 | 1000:1 | 500 cd/m2 | Inquiry Now |
| 15.0″ | 1024*768 | 4:3 | 1000:1 | 300 cd/m2 | Inquiry Now |
| 15.6″ | 1920*1080 | 16:9 | 800:1 | 300 cd/m2 | Inquiry Now |
| 17.0″ | 1280*1024 | 5:4 | 1000:1 | 300 cd/m2 | Inquiry Now |
| 19.0″ | 1280*1024 | 5:4 | 1000:1 | 300 cd/m2 | Inquiry Now |
| 21.5″ | 1920*1080 | 16:9 | 1000:1 | 300 cd/m2 | Inquiry Now |
| Product Features |
|---|
Technological Aesthetics Design
Upgraded Body Design
| Product Parameters | ||
|---|---|---|
| Hardware Parameters | CPU | RK3288 Cortex-A17 Quad-Core 1.8GHz/RK3399/RK3588 |
| Memory | 2G/4G/8G DDR4 Optional | |
| Storage | 32G/64G/128G/256G eMMC Optional | |
| OS | Android 7.1/10.0/12.0, Ubuntu18.04, Debian10.0, Linux4.4 | |
| GPU | ARM Mali-G52 MP2 | |
| Network Support | 4G, Ethernet, WiFi/Bluetooth support, wireless peripheral expansion | |
| Screen Parameters | Panel Type | Industrial control screen |
| Viewing Angle | Wide view / full view | |
| Backlight Type | LED, use time >=50000H | |
| Brightness | Brightness: 300cd/m2(can be customized =< 1500cd/m2) | |
| Display Color | 16.7M | |
| Contrast Ratio | 1000:1 |
| Touch Parameters | Projection capactivite touch Touch Point: 10-point Light Transmittance: >=88% Input Mode: handwriting or capactivite pen Standard Protocol:USB | Resistive touch 4-5wire/5 Wire Touch Point: single point Light Transmittance: >=78% Input Mode: Fingertip or stylus Standard Protocol:USB | Non-touch Light Transmittance: >=92% | ||
| Interface Parameters | DC Port | 1*DC2.1, Support 12V-36V wide voltage power supply |
| HDMI | High-definition audio digital signal transmission, support HDMI data input. | |
| SIM | 1*SIM, Supporting various formats (Depending on 3G/4G module) | |
| Network interface | 1*LAN, 10M/100M/1000M adaptive Ethernet | |
| VGA | 1*VGA | |
| Audio interface | 1*Audio I/O, Support audio input and output |
| Environment Parameters | Working Temperature | -20°C~70°C |
| Storage Temperature | -30°C~80°C | |
| ESD | Contact ±8KV, air ±15KV | |
| Shock Protection | IEC 60068-2-27, half sine wave, 11ms duration | |
| Relative Humidity | Humidity: 95% Non-Condensing | |
| Vibration Protection | IEC 60068-2-64, Random, 5 ~ 500 Hz, 1 hr/axis | |
| Impact Protection | IEC 60068-2-27, Half sine wave, Lasting for 11ms |
| Other Parameters | Power input | DC 12V~36V |
| Static power | 18W | |
| Body Color | White, Black Optional | |
| Installation Method | Supports snap-embedded,wall edbedded,wall mounted,desktop,louvered,cantilever-mounted,boom-mounted,etc. | |
| Warranty Policy | Three years ( one year free warranty ) |
