Medical S Series Windows Panel PC
Medical S Series X86 panel PC with X86 architecture is a compact and specialized computing device designed specifically for use in healthcare environments, particularly on medical carts. These panel PCs integrate a 10.1-inch touchscreen display with an X86-based processor, offering a balance of performance, reliability, and functionality tailored for clinical workflows.
TouchThink S Series Medical Grade Windows All-In-One Panel PC
| Product Size | Resolution | Aspect Ratio | Contrast Ratio | Brightness | Quick Inquiry |
|---|---|---|---|---|---|
| 10.1″ | 1280*800 | 16:10 | 1000:1 | 300 cd/m2 | Inquiry Now |
| Product Features |
|---|
Technological Aesthetics Design
Upgraded Body Design
| Product Parameters | ||
|---|---|---|
| Hardware Parameters | CPU | Intel Celeron J1900 quad-core 1.99GHz /J4125/J6412 |
| Memory | 2G/4G/8G DDR4 Optional | |
| Storage | 32G/64G/128G/256G eMMC Optional | |
| OS | Win7/10,Ubuntu/Centos/Redhat/Debian/Linux | |
| Integrated Graphics | Intel HD Graphics | |
| Network Support | 4G, Ethernet, WiFi/Bluetooth support, wireless peripheral expansion | |
| Screen Parameters | Panel Type | Industrial control screen |
| Viewing Angle | Wide view / full view | |
| Backlight Type | LED, use time >=50000H | |
| Brightness | Brightness: 300cd/m2(can be customized =< 1500cd/m2) | |
| Display Color | 16.7M | |
| Contrast Ratio | 1000:1 |
| Touch Parameters | Projection capactivite touch Touch Point: 10-point Light Transmittance: >=88% Input Mode: handwriting or capactivite pen Standard Protocol:USB | Resistive touch 4-5wire/5 Wire Touch Point: single point Light Transmittance: >=78% Input Mode: Fingertip or stylus Standard Protocol:USB | Non-touch Light Transmittance: >=92% | ||
| Interface Parameters | DC Port | 1*DC2.1, Support 12V-36V wide voltage power supply |
| HDMI | High-definition audio digital signal transmission, support HDMI data input. | |
| SIM | 1*SIM, Supporting various formats (Depending on 3G/4G module) | |
| Network interface | 1*LAN, 10M/100M/1000M adaptive Ethernet | |
| VGA | 1*VGA | |
| Industrial terminal | 1*Industrial terminal,Support wide voltage 12V-36V power supply |
| Environment Parameters | Working Temperature | -20°C~70°C |
| Storage Temperature | -30°C~80°C | |
| ESD | Contact ±8KV, air ±15KV | |
| Shock Protection | IEC 60068-2-27, half sine wave, 11ms duration | |
| Relative Humidity | Humidity: 95% Non-Condensing | |
| Vibration Protection | IEC 60068-2-64, Random, 5 ~ 500 Hz, 1 hr/axis | |
| Impact Protection | IEC 60068-2-27, Half sine wave, Lasting for 11ms |
| Other Parameters | Power input | DC 12V~36V |
| Static power | 18W | |
| Body Color | White, Black Optional | |
| Installation Method | Supports snap-embedded,wall edbedded,wall mounted,desktop,louvered,cantilever-mounted,boom-mounted,etc. | |
| Warranty Policy | Three years ( one year free warranty ) |
