TouchThink C Series Mini PC
Industrial computer C Series with high-strength aluminum alloy die-casting housing, sleek and minimalist design, lightweight and durable. Engineered to withstand harsh environmental conditions in industrial settings. Based on X86 or ARM architecture.
TouchThink Industrial Computer C Series
| CPU | Product Size | Weights | Body Colour | Quick Inquiry |
|---|---|---|---|---|
| RK3288 | W261.5 * H148.5 * D42.8 mm | 1.6KG | Gun black | Inquiry Now |
| RK3568 | W261.5 * H148.5 * D42.8 mm | 1.6KG | Gun black | Inquiry Now |
| RK3588 | W261.5 * H148.5 * D42.8 mm | 1.6KG | Gun black | Inquiry Now |
| RK3399 | W261.5 * H148.5 * D42.8 mm | 1.6KG | Gun black | Inquiry Now |
| J4125 | W261.5 * H148.5 * D42.8 mm | 1.6KG | Gun black | Inquiry Now |
| Intel I3 | W261.5 * H148.5 * D42.8 mm | 1.6KG | Gun black | Inquiry Now |
| Intel I5 | W261.5 * H148.5 * D42.8 mm | 1.6KG | Gun black | Inquiry Now |
| Intel I7 | W261.5 * H148.5 * D42.8 mm | 1.6KG | Gun black | Inquiry Now |
| Product Features |
|---|
Ultra-thin Frame Design
Industrial Technology Design
| Product Parameters | ||
|---|---|---|
| Hardware Parameters | CPU: RK3588 Octa-Core 64bit 2.4GHz | Android 12.0, Ubuntu/Debian/Linux |
| CPU: RK3568 Octa-Core 64bit 2.0GHz | Android 12.0, Ubuntu/Debian/Linux | |
| CPU: RK3399 Six-Core 64bit 1.8GHz | Android 7.1/9.0/11, Ubuntu/Debian/Linux | |
| CPU: RK3288 Cortex-A17 Quad-Core 1.5GHz | Android 7.1/9.0/11, Ubuntu/Debian/Linux | |
| CPU: Intel J4125 | Windows7/10/11; Ubuntu16.04.7/8.04.5/20.04.3; Centos7.6/7.8 | |
| CPU: I3/I5/I7 | Windows7/10/11; Ubuntu16.04.7/8.04.5/20.04.3; Centos7.6/7.8 | |
| Memory | 4GB/8GB/16GB/32GB/64GB Optional | |
| Storage | 64GB/128GB/256GB/512GB SSD, 1T/2T HDD Optional | |
| GPU | ARM Mali G610 MP4 | |
| NPU | 6TOPS AI computing power | |
| Network Support | 4G, Ethernet, wireless peripheral expansion,etc. | |
| Power On | Support | |
| Remote Wakeup | Support | |
| HD Support | Support | |
| Environment Parameters | Working Temperature | -10°C~60°C |
| Storage Temperature | -20°C~70°C | |
| Relative Humidity | Humidity: 95% Non-Condensing | |
| Vibration Protection | IEC 60068-2-64, Random, 5 ~ 500 Hz, 1 hr/axis | |
| Impact Protection | IEC 60068-2-27, Half sine wave, Lasting for 11ms |
| Other Parameters | Power input | DC 12V-36V |
| Sizes | 199.5*213.1*58.3mm (L*W*H) | |
| Weights | 1.9KG | |
| Static power | 15W | |
| Sliver, Black Optional | Gun black | |
| Installation Method | Supports desktop and rack mounting | |
| Warranty Policy | Three years ( one year free warranty ) |
